350 kW generators are essential for industrial and commercial applications where reliable and powerful energy solutions are necessary. This article provides a detailed analysis of several prominent models and their specifications, features, and applications, using tables for clarity. These generators include models like the Cummins NTAA855-G7A, Industrial Generators with SDEC Diesel Engine, Cummins Diesel Generator Set 350kVA, and others. We’ll explore their performance, technical aspects, and ideal use cases to assist in selecting the most appropriate model for specific needs.
1. Cummins NTAA855-G7A 360KW 450KVA Generator
The Cummins NTAA855-G7A is a high-performance industrial generator offering reliable power solutions for demanding environments. Below are its specifications, features, and applications.
Specifications:
| Attribute | Value |
|---|---|
| Model | NTAA855-G7A |
| Displacement | 14 liters |
| Number of Cylinders | 6 cylinders |
| Prime Power | 360 kW (450 kVA) |
| Standby Power | 360 kW (450 kVA) |
| Speed | 1500 RPM (50 Hz) |
| Cooling System | Water-cooled |
| Generator Set Model | HY-G360 |
|---|---|
| Prime Power (kW/kVA) | 360 kW/450 kVA |
| Standby Power (kW/kVA) | 360 kW/450 kVA |
| Output Voltage | 400/230V |
| Frequency | 50 Hz |
| Rated Current | 648 A |
| Rated Speed (RPM) | 1500 |
| Power Factor | COSΦ=0.8 (lagging) |
| Fuel Consumption | 204 L/hr |
| Battery Rated Capacity | 135 AH (2 pieces) |
| Gross Weight | 3300 kg |
| Dimensions (L×W×H) | 3300 × 1380 × 1850 mm |
Features:
| Feature | Details |
|---|---|
| Brand | CCEC |
| Engine Model | NTA855-G7A |
| Cylinder Configuration | 6 Cylinders in-line |
| Prime Power (kW/HP) | 407 kW/553 HP |
| Bore × Stroke (mm) | 145 × 152 |
| Displacement (L) | 14 L |
| Exhaust Temperature (℃) | 484 |
| Lubricating Capacity (L) | 36 L |
| Cooling Capacity (L) | 67 L |
| Fuel Consumption (g/kW.h) | 207 g/kW.h |
| Aspiration Method | Turbocharged |
| Starting System | Electrical start |
| Governor Type | Electrical Control |
Applications:
-
- Industrial Power Supply: Reliable energy for large-scale industrial facilities.
- Data Centers: Continuous power to maintain data security and business continuity.
- Hospitals: Backup power for critical medical equipment and operations.
- Construction Sites: Temporary power supply for various construction activities.
- Mining and Oil Fields: Stable power support in remote and challenging environments.
2. Industrial Generators with SDEC Diesel Engine (350kVA)
This generator, powered by the SDEC diesel engine, is ideal for industries requiring a reliable and efficient power source. Below is a detailed breakdown of its specifications, features, and application potential.
Specifications:
| Attribute | Value |
|---|---|
| Model | A-SH385-II |
| Engine Manufacturer | Shanghai Diesel Engine Co., Ltd. |
| Max. Power | 385 kVA |
| Engine Brand | SDEC |
| Engine Model | 6ETAA11.8-G21 |
| Rated Power | 350 kVA |
| Number of Cylinders | 6 in-line cylinders |
| Aspiration | Turbocharged & Air Aftercooled |
| Frequency | 50 Hz |
| Rate Voltage | 400/230 V |
| Displacement | 11.8 L |
| Dimensions (Open-type) | 3100 × 1150 × 1750 mm |
| Dimensions (Soundproof) | 3900 × 1300 × 1900 mm |
| Weight (Open-type) | 2650 kg |
| Weight (Soundproof) | 3600 kg |
Features:
| Feature | Details |
|---|---|
| Alternator Model | ASF314E |
| Voltage Regulation | AVR Model SX440 |
| Control Panel | Smartgen HGM6120N |
| Breaker Capacity | 630A |
| Protection Grade | IP23 |
| Altitude Capability | ≤1000 m |
| Insulation Class | Class H |
Applications:
-
- Commercial Power Generation: Supports large commercial operations with consistent output.
- Manufacturing Plants: Provides backup or primary power for manufacturing units.
- Remote Industrial Sites: Ideal for locations without direct grid access.
3. Cummins Diesel Generator Set 350kVA (WT-C388)
The Cummins WT-C388 is a versatile and efficient diesel generator. It meets various standards and is suited for multiple settings, including standby, emergency, and common use.
Specifications:
| Attribute | Value |
|---|---|
| Model Number | WT-C388 |
| Speed | 1500 RPM/1800 RPM |
| Output Type | AC Three Phase |
| Frequency | 50 Hz/60 Hz |
| Battery Voltage | 12V/24V |
| Cooling System | Water Cooled Radiator Engine |
| Governing Type | Electrical Starting (GAC) |
| Compression Ratio | 17:1 |
| Voltage Regulation | Maintained within 0.5% |
| Insulation Class | Class H |
| Dimensions | 3200 × 1050 × 1650 mm |
Features:
| Feature | Details |
|---|---|
| Voltage Options | 400/230V, 380/220V, 440/220V, etc. |
| Excitation Mode | AC Rotating Exciter |
| Noise Control | Low Noise Automation |
| Alternator Type | Brushless, Self-Exciting |
| ATS (Auto Transfer Switch) | Optional |
Applications:
-
- Emergency Backup Power: Ensures continuous operation during power outages.
- Agricultural Operations: Powers irrigation systems and other agricultural machinery.
- Industrial and Commercial Uses: Suitable for various heavy-duty applications.
4. XINHONGYUAN Industrial Diesel Generator XHYS-350GF
This open-type generator features the Kaipu engine, providing a robust power solution for heavy-duty applications.
Specifications:
| Attribute | Value |
|---|---|
| Model | XHYS-350GF |
| Rated Power | 350 kW (400 kVA) |
| Frequency | 50 Hz |
| Rated Voltage | 380 V |
| Engine Model | KP425 |
| Displacement | 11.8 L |
| Fuel Type | Diesel |
| Compression Ratio | 15.75:1 |
| Fuel Consumption | 210 g/kW.h |
| Oil Capacity | 33 L |
| Bore × Stroke | 135 × 165 mm |
| Dimensions | 3100 × 1400 × 1700 mm |
Features:
| Feature | Details |
|---|---|
| Alternator Model | HYF-400 |
| Warranty | 12 months or 1000 motor hours |
| Application Type | Open type |
Applications:
-
- Industrial Facilities: Reliable and durable power for factories and workshops.
- Infrastructure Projects: Power supply for large construction and infrastructure setups.
Conclusion
350 kW generators play a critical role in powering industrial and commercial facilities. Models such as the Cummins NTAA855-G7A, SDEC-powered units, and others provide a range of options for various applications, from emergency backup to continuous operation in remote locations. Selecting the right model requires careful consideration of specifications, features, and intended use, ensuring maximum efficiency and reliability for the specific requirements. Reach Out to us for the best referral.
